4G GPS Speed Limiter for Singapore

Prix normal
$59.00
Prix réduit
$59.00
Prix normal
$99.00
Épuisé
Prix unitaire
par

The speed limiter regime in Singapore aims to improve road safety and driving behaviour. It complements other measures intended to reduce fatalities and injuries among all road users.

Under Singapore’s laws, it is mandatory for speed limiters to be installed in the following categories of vehicles:

  1. every goods vehicle having a MLW exceeding 12,000kg and which has, or if a speed limiter is not fitted to it would have, a maximum speed exceeding 60km/h; and
  2. every public service vehicle having a MLW exceeding 10,000kg and which has, or if a speed limiter is not fitted to it would have, a maximum speed exceeding 60km/h.

Currently, lorries with a MLW between 3,501kg and 12,000kg (inclusive) are not required by law to have any speed management devices, or speed limiters. The law to have speed limiters will be expanded to all lorries in this weight category progressively over 1 January 2026 to 1 July 2027.

From Singapore Limiter Announcement

https://www.police.gov.sg/Advisories/Traffic/Traffic-Matters/Speed-Limiter-Announcement

GPS Speed limiter features:

1 Speed Limiter

Enforce to limit the speed of your vehicle if preset maximum speed

2 Tamper proof

Maximum speed is 40km/h if maximum speed is tampered or sensor is cut.

3 Download data

Data can be stored for 72 hours at interval of 5 seconds.

Data can be retrieved by connecting device to computer via USB data port

4 Bluetooth Printer

Violations can be printed out for the last one-hour driving. Portable printer prevents drivers from printing

Speed violations can be printed

5 Violations alarm

All violations will be transmitted to platform.

6 Over speed alarm

When vehicle reaches 95% of preset speed limit, built-in buzzer shall make sound alarm to warn driver.

7 Fuel monitoring (optional)

Monitor vehicle fuel consumption. Need connect with fuel sensor that gives out analog voltage.

Real time fleet tracking Working power: 2W

GPS speed limiter specs:

Name

UT04S GPS Speed Limiter

Weight

191g

Dimension

110*75*30 mm

Working voltage

DC 9V-36V

Backup battery

800mAh 3.7V

Battery working time

4hrs

Working current

60~150mA

Standby current

16mA

Charging current

Max < 500mA

Input Fuse

2A

Working power

2W

Working Temp.

-45~85

GSM Frequency

850/900/1800/1900 Mhz

Max RF output

33.0dBm±2dBm

Dynamic input range

-15 ~ -102dBm

GPS chipset

Ublox 7

GPS frequency

L1, 1575.42 MHz

GPS accuracy

5 meters at 2D RMS







Interface

1 A/D Port for fuel monitoring

1 Interface for data config by PC

1 USB port for USB disk data download

2 Port for speed limit

1 Input for speed signal

1 Input for Bluetooth Printing control

Built in Flash

Store data of last 72hrs, above 5000 points

Built in Buzzer

Sound alarm when speed reaches 95% of set value

Alarm

External power cut, Lower battery, Over speed, Geo-fence

Tracking method

Real time on Web Software and Phone APP

Account level

Unlimited sub account management

Report

Trip report, Speed report, Geo-fence report, Parking report, Driving Report, Alarm report, Mileage report, Engine Idle report


GPS speed limiter connection:

 gps speed limiter

ACC: (Orange) connected to vehicle ACC wire to detect engine ON/OFF

PULSE: (Purple) connected to vehicle speed signal wire to detect speed

GND / DC+: (Red and Black) connected to battery positive and ground.

GND / SOS: connected together with SOS button to control wireless printing. (With wireless Bluetooth printer turned on, press SOS button for 3 seconds, device shall beep, in 15 seconds device shall print last 1 hr data including over speed data. Long beep once all data is printed.)

NC / NO: (Green / Yellow) cut off fuel pump power wire, connect NO Yellow wire to the cut point, working as a power supply to fuel pump. (Relay and buzzer are built-in, when speed reaches 95% preset value, beep; 100% speed reached, built-in relay is activated with continuous beep.

Fuel (Grey) connect with fuel sensor signal wire to monitor fuel consumption (Optional)

 SIM slot: insert SIM card

Micro USB: connect device to PC for config

USB disk: insert USB disk for data download (beep sound after inserting, long beep once all data is downloaded.)

SW: built-in backup battery switch. (Default OFF)

RESET: one click to restart device

 LED: Blue for GPS (ON if signal okay), Green for GSM (slow flash if signal okay)
